Lexmark X642e - Page 509

Index I-1
7002-xxx
Index
Numerics
250-sheet paper drawer, option 7-59
250-sheet paper tray, option
parts catalog
7-60
service check 2-147
2xx paper jam and paper handing errors 2-57
500-sheet paper drawer, option 7-61
500-sheet paper tray 7-30
500-sheet paper tray, option
parts catalog
7-62
service check 2-147
80 scheduled maintenance 6-1
8xx Service error codes 2-13
900.xx error code service check 2-118
950.00 through 950.29 EPROM mismatch failure 2-120
950.30 through 950.60 EPROM mismatch failure 2-121
9xx Service error codes 2-14
A
acronyms 1-18
adjustments
fuser solenoid
4-2
gap adjustment 4-2
paper alignment assembly 4-3
printhead assembly 4-2
scanner registration 4-4
alignment assembly
adjustment
4-3
parts catalog 7-28
removal 4-122
ASIC Test 3-23
autocompensator, integrated tray
parts catalog
7-25
pick roll installation 4-106
removal 4-103
autoconnect connectors, bottom 5-8
autoconnect connectors, front 5-8
automatic document feeder (ADF)
parts catalog
7-17, 7-18, 7-19, 7-20, 7-57, 7-58
removals 4-6
sensor locations 5-2
B
barcode, system board 7-41
bevel gear
installation
4-76
removal 4-75
blower duct 7-15
Button Test 3-8
buttons
accessing service menus
3-1
Button Test 3-8
upper front cover including buttons 7-7
upper front panel button kit 7-7
C
cable diagrams 7-43, 7-44, 7-45, 7-46, 7-48, 7-50
cabling diagrams 7-52, 7-56, 7-57
CACHE Test 3-9
Configuration ID 3-19
configuration menu
accessing
3-1, 3-24
ADF Edge Erase 3-29
Automatic Scanner Registration 3-30
available menus 3-24
Disk Encryption 3-32
Energy Conserve 3-28
Envelope Prompts 3-32
EVENT LOG (print only) 3-31
Factory Defaults 3-28
FB Edge Erase 3-30
Font Sharpening 3-34
Format Fax Storage 3-29
Jobs On Disk 3-32
Key Repeat Initial Delay 3-35
Key Repeat Rate 3-35
LES Applications 3-34
Maintenance Page Count 3-25
Min Copy Memory 3-29
Panel Menus 3-27
Paper Prompts 3-31
PPDS Emulation 3-27
Print Quality Pages 3-26
Require Standby 3-34
Reset Maintenance Counter 3-25
SIZE SENSING 3-26
Wipe Disk 3-33
Wiper Message 3-35
configurations, models 1-1, 1-2, 7-1
connector locations
autoconnect—bottom
5-8
autoconnect—front 5-8
connectors
flatbed interconnect card
5-26
fuser board 5-9
high voltage power supply (HVPS) 5-9
interface card 5-10
LCD inverter board (IUCC #2) 5-16
low voltage power supply (LVPS) 5-11
modem card 5-31
motor driver board 5-23
operator panel card (UICC #1)—model X642e 5-12
operator panel card (UICC #1)—models X644e/X646e
5-14
scanner control card 5-17
system board 5-3
USB card 5-10
