11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 180

Some error log events were disappeared if the last error was too close in time.
:HDCPRESET command may have freezeed the communication
HDCP LED sometimes had false blinking on MX-HDMI-IB
There was erroneous HDCP handling if more than 20 keys were received from an HDCP capable sink.
This may have resulted reboot.
3.1.8
Released: 2011-09-30
New feature
MX-DVI-OPT-OB v24 support.

The response for {VM} command (View Mute state) now starts with "MUT" (not "ALL") according to the
product manual.
Matrix may have restarted because of internal communication problems in case of DVI-HDCP and

3.1.9
Released: 2011-10-10


was missing at the end of the line.
3.2.0
Released: 2011-11-02


3.2.2
Released: 2011-11-23

            


3.2.3
Released: 2011-12-12
New feature
Supports MX-3GSDI-IB.
3.2.5
Released: 2012-02-20

New standard timing descriptors are applied. Standard resolution list now contains 1024x768@60 and
1920x1080@60 resolutions.
Factory EDIDs had a bug - the digital sync was not set properly in the detailed timing descriptor blocks.
Sometimes this caused error with analog sources.

Preview output didn't convert down the deepcolor modes to HDMI 24bit in auto mode if the display
didn't support deepcolor.
An extra 0-byte length short descriptor was present in the CEA data block. This may have led to
incompatibility with some sources.

threshold on the DVI-I board.
ASUS EAH3650 video card can send a strange analog format in 1280x720p60 and 1920x1080p60.
These resolutions are added to the factory preset list now.

On the 4 line LCD at the "Switch EDID" menu item it is possible to select factory and user EDIDs, not just
dynamic EDIDs.
Too many cached HDCP keys could lead to reboot.
If an EDID switch happens while the source is reading the data, then the input board could fail (MX-
HDMI-IB, MX-DVI-HDCP-IB, MX-HDMI-TP-IB)
3.2.6
Released: 2012-03-01
New feature
In case of FR33R the insertion and removal of the PSUs are logged.

The matrix could fail to boot in case of wrong RTC.
Invalid EDIDs cannot be switched to input ports anymore.

HDCP handling of preview output in MX-FR80 didn't work properly.
MX-HDMI-OPT-IB didn't detect if the link was terminated. (The bug appeared in 3.1.6)
3.2.7
Released: 2012-05-30
New feature
Support for MX-FR33L
            
signals.
