Maintenance 5
Gearbox
Checking the drive axle bearings for
wear
NOTE
The drive axle is installed in t
he chassis with
rubber spring elements on both
sides.
¾ Remove the drive wheels.
d3921498
11
¾ Using a lamp, check the state of the rubber
spring elements (1) between the axle, chas-
sis and plastic stops.
The rubber spring elements mus
t be checked
on both the left and right of the
axle. If the axle
spring elements or the plast
ic stops are worn,
these must be changed. Pleas
e contact your
authorised dealer.
¾ Attach the drive wheels.
Checking the hydra
ulic pump’s at-
tachment to the eng
ine
¾ Open the bonnet.
¾ Tighten the 4 hexagon head screws to the
prescribed tightening torque of 80 Nm.
¾ Close the bonnet.
Operating Instructions – 393 807 1001 EN – 08/2008 149
