Maintenance 5
Troubleshooting
(3), and then from the current-giving battery
(5).
¾ First disconnect the positive cable (1) from
the current-giving battery (5), then from the
discharged battery (2).
Fork carriage emergency lowering
If there is a malfunction, the fork carriage can
be lowered manually.
¾ Remove floormat.
DANGER
People are not allowed to stand in
the vicinity of the fork arms when
they are being lowered.
During lowering, leave the socket
wrench on the screw (1) on the valve
block (3) to enable lowering to be
interrupted at any time.
¾ Insert the 8 mm WAF socket wrench
through the opening in the floor plate.
¾ Slowly rotate the screw (1) using the socket
wrench approx. 1.5 turns in an anti-clock-
wise direction until the fork carriage has
been completely lowered.
¾ Open the bonnet.
¾ Open floor plate and secure it.
¾ Undo the self-locking nut (2) about 2 turns.
Operating Instructions – 393 807 1001 EN – 08/2008 189
