Linde H35D - Type Sheet H 35, as at 05;2008

6 Technical data
Type sheet H 35, as at 05/2008
Type sheet H 35, as at 05/2008
1 Identification
1.1
Manufacturer
Linde
1.2
Manufacturer’s model designation
H35D
1.3 Drive Diesel
1.4
Operation
Seated
1.5
Load capacity / Load Q[kg]
3500
1.6
Load centre of gravity c [mm]
500
1.8 Load distance
x [mm]
450
1.9 Wheelbase
y [mm]
1965
2 Weight
2.1
Tare weight kg
4680
2.2
Axle weight with front/rear load
kg
7240 / 940
2.3
Axle weight without front/rear load
kg
2050 / 2630
3 Wheels, chassis frame
3.1
Front/rear tyres: polyurethane, rubber
SE
3.2
Tyre size, front
27x10-12
21
3.3
Tyre size, rear
23x9-10
22
3.5
Wheels, number, front/rear (x = driven) 2x (4x)/2
23
3.6 Front track width
b10 [mm] 1008 (1204)
24
,
25
3.7
Track width, rear
b11 [mm]
932
4 Basic dimensions
4.1
Forward/backward fork tilt
α/β (°)
5.0/8.0
26
4.2
Lowered mast height h1 [mm]
2264
27
4.3
Free lift
h2 [mm]
150
21
Optional: 7.00-12 dual fitment (air/SE). Single tyres air 27x10-12 and SE 28x12.5-15.
22
Optional: air 23x9-10.
23
Bracketed value for dual fitment.
24
1042 mm with tyre size SE 28 x 12.5 - 15.
25
Bracketed value for dual fitment.
26
Lift height and equipment can change the backwards tilt.
27
With 150 mm free lift on standard lift mast.
210 Operating Instructions – 393 807 1001 EN – 08/2008
