Linde H35D - Check the Parking Brake for Correct Operation

5 Maintenance
Chassis frame
Check the parking brake for correct
operation
¾ Drive the fork lift truck, carrying its maximum
load, up a gradient of 15 %.
d3921457
1
¾ Pull the parking brake handle (1) upwards.
The vehicle must remain stati
onary.
¾ Switch off the engine.
Version 1:
¾ Release the parking brake handle
(1).
The vehicle must remain stationary.
Version 2:
¾ Place the parking brake lever (2) in a hori-
zontal position.
The vehicle must remain stationary.
¾ Switch off the engine.
¾ Press the button (1) and unlock the parking
brake lever (2).
¾ Move the parking brake 90° downwards.
The vehicle must remain stationary.
NOTE
If the parking brake fails this test, contact your
authorised dealer.
162 Operating Instructions – 393 807 1001 EN – 08/2008
