Operation 4
Standard equipment
NOTE
Driver’s cabs with fixed closed doors or bra-
cket doors satisfy the safety requirements for
driver restraint systems. The seat belt can be
used in addition. It must, however, be affixed
when driving with doors that are open or have
been removed. PVC doors do not constitute
an operator restraint system. For trucks with
the "speed reduction" special function, the
seat belt must be worn even at the reduced
speed.
The automatic blocking mechan
ism prevents
the belt from being extended wh
enever the in-
dustrial truck is on a steep s
lope. It is then not
possible to pull the belt any
further out of the
retractor. To release the au
tomatic blocking
mechanism carefully move th
e truck so that it
is no longer positioned at an
angle.
While using the truck (e.g. driving, operat-
ing lift mast etc.), adopt a sitting position as
far back as possible so that the driver’s back
rests against the seat backrest. The automatic
blocking mechanism of the belt retractor offers
sufficient freedom of movement on the seat for
normal use of the fork-lift truck.
d3921415
3
2
1
5
4
¾ Draw seat belt (1) smoothly from the retrac-
tor on the left.
¾ Position belt over lap, not o
ver stomach.
¾ Allow buckle (2) to snap into place in catch
lock of belt (4).
¾ Check seat belt tension.
Belt must fit close to the body
.
Open seat belt
¾ Press the red button (5) on the buckle (4).
¾ Feed the buckle (2) manually back into the
retractor (3).
NOTE
The automatic blocking mechan
ism may be
triggered if the belt runs in
too quickly when the
buckle strikes the housing.
The belt cannot be
pulled out with normal force
.
Operating Instructions – 393 807 1001 EN – 08/2008 31
