Operation 4
Standard equipment
Switching off the engine
CAUTION
For engines with a turbocharger, the high speed
of the turbocharger shaft (approx. 100 000 rpm at
full load)could cause the shaft bearing to run dry
through lack of lubrication thus damaging it.
Do not switch off engine under full load, but rather
allow to run on for a few minutes at low speed.
¾ Remove foot from accelerator pedal (3).
4
d3921362
¾ Move the direction of travel lever (4) into the
neutral position.
¾ Turn the ignition key (2) to the zero position.
NOTE
The brake is applied when the engine is swit-
ched off.
¾ Apply the parking brake.
• Version 1: Pull up the parking brake handle
(1).
• Version 2: Turn the parking brake lever (16)
clockwise until it snaps into place.
¾ Remove the ignition key (2) when leaving
the truck.
Operating Instructions – 393 807 1001 EN – 08/2008 41
