LNC T6 Series User Manual

LNC-Lathe New T6-Series
CNC Operation
14 LNC Technology Co., Ltd.
【RELATIVE COORDINATE】
Pressing 【REL.】to enter into the relative coordinate screen. Details will be shown in bigger words at the upper
left side of the screen. The relative coordinate system means the distance between the present position and any
point that is decided by users. So users can set the relative coordinate value to zero at anytime, or enter the
non-zero value directly.
The way for relative coordinate to return zero：
If want to set the 3 axes relative coordinate values to zero separately or at the same time, users only need to
press the corresponding sub-function buttons 【CLR. X】, 【CLR. Y】, 【CLR. Z】, 【CLR. ALL】 to execute
the corresponding clean.
Setting way for relative coordinate：
If you want to reset the coordinate value and to let X coordinate to 100.00, Y coordinate to 200.000 and Z
coordinate to 300.000, only need to set X100, Y200, Z300. Then, pressing <INPUT> to reset the coordinate
value immediately.
REL
