LNC-Lathe New T6-Series
OP Panel Operation
LNC Technology Co., Ltd. 119
2.7 EMG-STOP
Using this butting under the condition of danger or emergency and all motions will stop. To cancel is to turn the
button by following the arrow direction. When the button is jump up automatically, the emergency stop is
released. When the button is pressed, the system is in “Not Ready” condition (condition column will occur “Not
Ready”). In order to reach completed safety, the feed driver power in the power cabinet will be disconnected.
Before releasing emergency stop, please ensure whether or not the broken source is excluded. Please
executing home return procedure after the emergency stop is released in order to ensure the accuracy of the
coordinate position.
Note：When you press EMG-STOP, you will need to do return ZRN every time while you release it. But absolute
encoder is not included in.
2.8 CYCLE START&FEED HOLD
CYCLE START
After key-in a program, switching the operation mode to MEM or MDI mode and pressing “CYCLE START”
button to executing programs. While the program is executed, this light will be ON. The timings of using “CYCLE
START” button are the following：
a. Auto executing in MEM mode
When a program is selected in MEM mode, press “CYCLE START” button to execute the program. The light
will remain ON during program executing time until the program execution is finished. Before executing
program, the three axes must return home. If not returning back to home, users can switch the “Reference
Need to OFF” on the Users Define screen. By doing this, program will be able to execute without returning
back to home.
