13.0 Setup Menu
13.5 Trig Screen
Controlswhethertheloaderpositiongraphicisdisplayed.
n
SelecteitherOnorOff,thenpress .
13.6 Language
The language can only be changed if LanguageEdit functionality has been enabled during installation.
DisplaysalistofavailablelanguagesinwhichtheLoadriteIndicatorcandisplayscreennames,fields,menu
optionsandprintedtickets.
n
Selectyourpreferredlanguage,thenpress .
13.7 Edit Password
A password can only be edited if Login functionality has been enabled during installation.
AllowsthePINnumberofthecurrentoperatortobechangedusingthekeypad.
n
EnterthenewPINnumberusingthekeypad,thenpress .
13.8 Scale #
The Scale options are only available if Multiple Scales functionality
has been enabled during installation.
Thisoptionenablestheuseofdifferentloadbearingimplements(forexample,bucketorforks)ontheloader.
Theoperatorneedstoselectthecorrectscalefortheattachedimplement.
TIP – Youshouldperforma CheckZero afterchangingtheattachment.
13.9 Module
The Module option is only available if a Loadrite Data Module is connected to the Indicator and
DataLogger functionality has been correctly configured during installation.
The DataModuleMenu providesfunctionalityforusewithLoadriteDataModules.
Thefollowingmenuitemsareavailable:
Option Description
Property ListsthepropertiesoftheDataModule.
Backup SavestheproductlistanddataliststotheDataModule.
Loadrite L2180 loader scales | 68
