16.0 Appendix C: Error Messages
16.5 Calibration Reminder
Thismessagedisplaysonstart-upasareminderthatacalibrationisduetobeperformedontheLoadrite
WeighingSystem.DependingontheconfigurationoftheIndicator,theremindermayalsodisplaywhenin
Standbymode.
NOTE – ThismessageshouldonlybedisplayedifCalibration Reminderfunctionalityhasbeen
enabledandconfiguredatinstallation.
16.6 Check power
Thepowersupplyhasreachedanunstablelevel.Checkthatthepowersourceisstableandbetween+12V
and+32V.
16.7 Check MAG/OPT
Thereisafaultinthemagneticoropticaltriggerorthecablethatconnectsthetrigger.Ifusinganopticaltrigger,
checkthatthelensisclearanddust-free.
16.8 Check rotary
Thereisafaultintherotarytriggerorthecablethatconnectsthetrigger.Checkthatthetriggerisstillsecurely
mountedandthatthetriggerfingerhasnotbeendamaged.
16.9 Check scale#
Thismessagedisplayswhen ispressediftheIndicatorissetupforusewithmultiplescales.
Iftheweightisgreaterthan10%offullbucketcapacityfortheselectedscalenumber,thescreendisplays
Check Scale#message.Theoperatorneedstoensurethecorrectscalenumberisselectedfortheattached
implement,asimplementsdifferconsiderablyinweight.
16.10 Check tilt
Thereisafaultinthetiltsensorusedforgroundslopecompensationorthecablethatconnectsthesensor.
Checkthatthetiltsensorisstillsecurelymountedandthatthecablehasnotbeendamaged.
16.11 Check transducer
Thereisanerrorinthepressuretransducersignalinput.Thisindicatesafaultineitherthepressuretransducer
orthecablethatconnectsthetransducer.
16.12 Check zero
Theoperatorisautomaticallyremindedtozerothebucket.
