14.0 Appendix A: System specifications
14.5 Environmental specifications
Operating temperature -10°C~50°C(14°F~122°F)
Tactile keypad -50°C~100°C(-58°F~212°F)
Weight ProtectedtoIP54.
Dimensions ProtectedtoIP69.
TheIndicatorwear-outmechanismshavebeenevaluatedandimprovedthroughseveraliterationsofcyclic
thermalstressbetween-90°Cand+110°Cwithsimultaneous6-axisrandom,repetitiveshockexceeding
50Grms.
14.6 Signal inputs and outputs
Pressure transducer input 4-20mA(0-100%)
Trigger
Trigger1:MagneticorOptical.Pull-upresistorwithswitchtoground.
Trigger2:Rotary.Pulsewidthmodulated0-5V.
Serial communications RS232CprotocoltoprinterandLoadriteDataModule.
14.7 Clock
Built-in clock Hours,minutes,day,month,year.
14.8 Output / Input connections
