Chapter 10. Enclosure Management
180 3ware SATA+SAS RAID Controller Card Software User Guide, Version 10.2
Viewing a List of Enclosures
If you have multiple enclosures attached to your 3ware RAID controller, you
can see a list of them.
To see a list of enclosures in 3DM2
• Choose Monitor >> Enclosure Support from the menu.
The Enclosure Summary screen appears.
Figure 87. Enclosure Summary page
To see details about a particular enclosure, click the link in the ID column.
(For more information, see “Checking Enclosure Component Status” on
page 181.)
To see a list of enclosures in 3BM
1 On the main 3BM screen, Tab to Information and press Enter.
2 On the pop-up menu, select
Enclosures and press Enter.
The Enclosure Information page appears, with information about
enclosure components displayed in the top section, and details about the
slots in the selected enclosure displayed in the bottom section.
For an explanation of statuses for the different components, see the status
topics starting under “Fan Status” on page 183.
3 On the Enclosure Information page, use the arrow keys to move from one
enclosure to another. You can use the - and Shift+ keys to hide or show
details about an enclosure, if desired.
Tip: You can scroll both sections of the Enclosure Information page to
bring additional enclosure information or enclosures into view. Press
Tab
to move between the two sections.
