Alarms page
www.lsi.com/channel/products 217
Alarms page
Figure 107. Alarms Page
The Alarms page appears when you click Monitor >> Alarms on the menu
bar.
This page displays a list of AENs (asynchronous event notifications) received
from the controller displayed in the drop-down list in the menu bar.
Up to 1000 events can be listed. After the 1000-limit is reached, the oldest
events are deleted, as new ones occur.
You can sort the events by severity or time. To do so, just click the column
header.
For information about a particular event, click it on the Alarms page; the
3DM2 Help will open with information about the event. For a complete listing
of the alarms that appear on the Alarms page, see “Error and Notification
Messages” on page 235.
Clear Alarms. The Clear Alarms button removes all alarms shown in the list.
Sev. Shows the severity of the event. Three levels are provided:
• Errors are shown next to a red box
• Warnings are shown next to a yellow box
• Information is shown next to a blue box
