Appendix B. Driver and Software Installation
342 3ware SATA+SAS RAID Controller Card Software User Guide, Version 10.2
Installing 3ware RAID Controller Management
Software for VMware
3ware RAID controller management software includes 3DM2 and CLI. CLI
can run locally on the VMware server in a console window.
By default, VMware ESX Server 4.0 does not have a GUI and therefore you
cannot access 3DM2 locally. You must use another system that has a GUI and
a web browser to access 3DM2.
After initial installation and setup, administration will typically be done
remotely through CLI or 3DM2.
If you have not yet installed 3DM2 and CLI, use the steps below to do so.
1 Mount the 3ware software image CD.
mount -t iso9660 /dev/cdrom /mnt/cdrom
2 Navigate to the appropriate directory where the 3DM2 and CLI rpm files
are located.
cd /mnt/cdrom/packages/installers/tools/vmware/esx40/
3 Run the install commands for CLI and 3DM2.
rpm -ivh <LSI-3ware-CommandLine-Management-Utility-xxx.rpm>
rpm -ivh <LSI-3ware-3dm2-Management-Utility-xxx.rpm>
4 Note the URL supplied by 3DM2 at the end of installation, (for example,
https://10.0.0.2:888), as it will be required in order to connect to 3DM2
through a web browser.
Uninstalling 3ware Software on VMware
You can uninstall CLI, 3DM2, and the 3ware RAID controller driver.
1 Login as root.
2 Check for installed packages.
esxupdate query
You will see a list of the packages that have been installed on VMware.
3 Run the command
Prerequisite to Software Installation:
You need a copy of:
Software utilities 3DM2 and CLI are available on the management software CD.
You need to download the LSI 3ware management software CD from the LSI
website at: http://www.lsi.com/channel/ChannelDownloads and burn the image to a
CD.
