Chapter 4. 3ware BIOS Manager (3BM) Introduction
36 3ware SATA+SAS RAID Controller Card Software User Guide, Version 10.2
Highlight the board with which you want to work and press Enter.
You see a screen similar to the following warning message, warning you
that changing your disk array configuration might overwrite data on the
disks.
Figure 20. Warning Message When you Start 3BM
6 Press any key to continue to the 3BM BIOS Manager screen.
Exiting the 3BM Configuration Utility
When you are ready to exit the 3BM configuration utility, you can save the
configuration changes you have made, or to discard the changes.
To save your configuration modifications
1 Press the
F8 or Esc key.
A list of affected drives appears, a message asks you to confirm the
configuration.
2Type
Y.
The booting process resumes.
Note: If you have a combination of older 3ware controllers in your
system, the older controllers are not listed on the selection screen
shown in Figure 19. Instead, an additional BIOS summary appears,
similar to Figure 18.
If you have two of the same series controllers that have different
versions of the firmware installed, they will also appear in different
BIOS summaries, and will launch different versions of 3BM.
