Working in the 3BM Screens
www.lsi.com/channel/products 37
To exit without saving changes
1 Press
Esc.
2 If you have unsaved changes, 3BM asks you whether you want to save the
changes and exit, or exit without saving the changes.
• If you want to exit without saving changes, type
N.
• If you change your mind and want to save the changes, type
Y.
Working in the 3BM Screens
The main 3BM screen (Figure 21) shows the current configuration for the
drives attached to your controller, and a list of any available drives. Unusable
and incomplete drives are also shown.
Figure 21. 3BM Main Display
The following sections appear in the main 3BM screen:
•
Available Drives lists any unconfigured drives that are not associated
with an array, and hot spares. If this section does not appear, there are no
available drives.
•
Direct Attached lists the drives directly attached to the controller.
•
Enclosure lists the drives attached through an enclosure.
•
Exportable Units lists the existing units and the drives contained in each
unit. These are the units that are available to the operating system when
Exception: Changes made to controller policies are saved when you leave the
Policy screen. Pressing F8 is not required to save those changes. For more about
changing policies, see “Setting the Auto-Rebuild Policy” on page 71.
