Chapter 4. 3ware BIOS Manager (3BM) Introduction
38 3ware SATA+SAS RAID Controller Card Software User Guide, Version 10.2
you boot your computer. If this section does not appear, no units have
been configured.
If you have more than one unit, the boot unit is the one at the top of the
list. (You can change the order by highlighting a unit and pressing the
PgUp or PgDn key.)
•
Unusable Arrays lists any RAID configuration missing too many drives
to construct the unit. For example, a RAID 5 unit with two or more drives
missing appears in this list.
•
Incomplete Drives and Others lists drives that are remaining from a unit
with missing or failed drives and drives that are not usable.
When some of the drives are remaining from a unit, you can power down
and add the missing drives to complete the unit. To use drives that are
listed here in other units, you must first delete them. For more
information, see “Deleting a Unit” on page 121.
If any of the sections are not shown, it means that there are no items of that
type connected to the controller.
Table 6 lists how to move around and select information in the 3BM screens.
When these commands are available in 3BM, they appear at the bottom of the
3BM screen.
Table 6: Working in 3BM
To do this Use these keys
Move between units or drives in a list,
between fields, and between buttons.
Up and Down Arrow Keys
OR
Left and Right Arrow Keys
OR
Tab and Shift+Tab
Select (or unselect) what is currently
highlighted.
A selection may be a drive in a list of
drives, a button at the bottom of the
screen, or a field in the middle of the
screen.
In lists, an asterisk appears to the left of
selected drives or units.
Enter or the Spacebar
Show a drop-down list of available
choices in a field.
Enter
Move between choices in a field list. Up and Down Arrow Keys
Select all available drives. Alt+A
