Chapter 5. 3DM2 (3ware Disk Manager 2) Introduction
56 3ware SATA+SAS RAID Controller Card Software User Guide, Version 10.2
Description of 3DM2 Pages
The following table describes 3DM2 pages, including their uses. Details
about each page and the fields and features on it are provided in Chapter 11,
“3DM2 Reference”. The page names in the table provide links to details about
that page.
In addition, the step-by-step instructions provided in the chapters on
configuring and maintaining your RAID controller and units explain how to
do particular tasks in 3DM2.
Table 7: List of 3DM2 Pages
3DM2 Page Description
Controller
Summary page
Provides basic information about each 3ware RAID controller
in your system.
To see this page, click Summary in the menu bar.
Controller Details
page
Provides detailed information about the current controller.
To see this page, select Information >> Controller Details
from the menu bar.
Unit Information
page
Shows a list of the units on the current controller and provides
summary information about each unit.
To see this page, select Information >> Unit Information
from the menu bar or click an ID number on the Controller
Summary.
Unit Details page Shows details about a particular unit.
To see this page, click an ID number on the Unit Information
page.
Drive Information
page
Shows a list of drives on the current controller and provides
summary information about each drive.
To see this page, select Information >> Drive Information
from the menu bar.
Drive Details
window
Shows the SMART data for a specific drive, and shows
additional detail information for the drive.
To see this page, click the Port # for a drive on the Drive
Information page.
