LSI 3ware 9750 User Manual

Working with the 3DM2 Screens
www.lsi.com/channel/products 57
Controller Phy
Summary page
Shows the properties of controller phys for 9750 RAID
controllers.
There are two ways to access this page. If you have a direct-
attached drive you can access this page from the Information
>> Drive Information page by clicking the phy ID for the
drive. If all drives are connected via expanders, select
Management >> Controller Settings page. Under Other
Controller Settings click the # link for Number of Controller
Phys.
Controller
Settings page
Lets you view settings that affect the units on the current
controller and change some of those settings.
Controller-level settings that can be changed include
background task rate, Auto-Rebuild, Auto-Carving, and Carve
Size. Some additional policies are shown that can only be
changed only in the BIOS or the CLI.
Unit-level settings include specifying the StorSave Profile and
enabling or disabling the Write Cache, Read Cache, Auto-
Verify, Overwrite ECC, Queuing, and Rapid RAID Recovery.
To see this page, select
Management >> Controller
Settings from the menu bar.
Scheduling page Lets you view and change the schedule for tasks that affect all
units on the current controller.
To see this page, select Management >> Scheduling from
the menu bar.
Maintenance
page
Lets you configure new units and make changes to existing
units.
To view this page, select Management >> Maintenance from
the menu bar.
Alarms page Shows a list of alarms, including the specific alarm message,
and the exact date and time it occurred.
To view this page, choose Monitor >> Alarms on the menu
bar.
Battery Backup
page
Shows the status of a Battery Backup Unit (BBU), if one is
installed, and allows you to test the battery.
To view this page, select Monitor >> Battery Backup on the
menu bar.
Enclosure
Summary page
Lists the installed and supported enclosures attached to your
3ware controller.
To view this page, select Monitor >> Enclosure Support on
the menu bar.
Table 7: List of 3DM2 Pages
3DM2 Page Description
