Programming Procedures
Page 3-51Lines and Trunks
3
Console/Display Instructions Additional Information PC
! Specify the type of trunks connected to the module.
! Enter the port numbers that have ground-start or loop-start trunks connected.
400 GS/LS and 408 ports:
n = 1 to 4; 800 ports: n = 1 to 8.
! Continue to assign trunk types, or go to Step 8.
Select
1H[W.

Return to Step 6. The next slot number
is displayed on Line 1.
! Save your entry.
Select
(QWHU.

! Return to the System Programming menu.
Select
([LW twice.

*6/66ORW YY 
 = 400 GS/LS, 408 GS/LS,
6HOHFWRQH
408 GS/LS-MLX,800 GS/LS, or
*URXQG6WDUW $OO*URXQG
800 GS/LS-ID.
/RRS6WDUW $OO/RRS
xx = slot number entered in Step 3
Select
*URXQG6WDUW or

([LW
/RRS6WDUW and go to Step 6.

Or, select
$OO*URXQG or

$OO/RRS and go to Step 9.

6WDUW6ORW YY 
 = option name selected in Step 5
(QWHUSRUWQR
xx = slot number entered in Step 3
NOTE:
If you get the Trunk Busy message,
wait for an idle condition or exit
system programming and try again
later.
%DFNVSDFH 1H[W
([LW (QWHU
Dial or type [ n ].
