Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-92Lines and Trunks
3
The system provides an error tone when a line/trunk is in use, or if a loudspeaker
paging system, Music on Hold, or maintenance alarm is already assigned;
however, the system does not indicate the reason for the error tone.
NOTE:NOTE:NOTE:
This procedure applies to Hybrid/PBX mode only.
Summary: Trunks to Pools Assignment 3
Programmable by System Manager
Mode Hybrid/PBX
Idle Condition Trunk idle
Planning Form Form 2c, System Numbering: Line/Trunk Jacks
Factory Setting All loop-start trunks are assigned to the main trunk pool
(factory-set extension number 70); all tie trunks are assigned
to the trunk pool with the factory-set extension number 891.
No factory-set extension numbers are assigned to
ground-start trunks.
Valid Entries Line numbers
Inspect Yes
Copy Option Yes
Console Procedure To program a single line/trunk:
/LQHV7UXQNV→3RROV→Dial pool dial-out code→
Select entry mode→Dial no. of the line/trunk→
(QWHU→([LW→([LW
To program a block of lines/trunks:
/LQHV7UXQNV→3RROV→Dial pool dial-out code→
Select block of lines/trunks→Toggle LED On/Off→
(QWHU→([LW→([LW
PC Procedure To program a single line/trunk:

→→Type pool dial-out code→→→
Type no. of the line/trunk→→→
To program a block of lines/trunks:

→→Type pool dial-out code→→Select block of
lines/trunks
→Toggle letter R On/Off→→→
