MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-273Extensions
3
Console Display/Instructions Additional Information PC
! Assign or remove the specified line/trunk number.
Select
(QWHU or
'HOHWH.
You may continue to assign or remove lines/
trunks by repeating Steps 2 and 3.
! Assign a single line/trunk to the next extension or go to Step 5.
Select
1H[W
Return to Step 2 to continue programming. The
next extension is displayed on Line 1.
! Return to the System Programming menu.
Select
([LW twice.
◆ Block Procedure
Console Display/Instructions Additional Information PC
! Specify the block of 20 lines associated with 20 buttons
on the system programming console.
Select
/LQHV
/LQHV
/LQHV
/LQHV.
! Assign or remove the line/trunk to or from the line button.
Toggle the green LEDs next to each
line button on or off as required.
On = line/trunk or pool assigned to extension
Off = line/trunk or pool not assigned to extension
For Hybrid/PBX only:
The red LED indicates:
On = trunk assigned to pool
Off = trunk not assigned to pool
! Save your entry.
Select
(QWHU.
! Return to the System Programming menu.
Select
([LW two times.
To Next Page
