100 Chapter 6
LightPath Analysis Software Guide
Feature Extract Length (m)
Once a Peak or other feature is detected by the software, a segment of data is
extracted around that location for further processing. The length of this segment is
specified by the Feature Extract Length parameter specified by the user.
Primarily, this parameter is used for processing of Peak features that are found in
the data set. However, this value is also be used as the area over which to calculate
the Return Loss of all features. It is used in determining whether the Drop
Tolerance and Peak Tolerance criteria are violated by each feature.
If two peaks are found close to each other and the extracted segments around those
peaks overlap, the peaks are combined into a single feature.
Default Value: 0.1
meters
Closely Related To: Peak Dead Zone, Peak Tolerance, Drop Tolerance
6
