Optical Backscatter Reflectometer 4600 107
User Guide
Drop Tolerance (dB)
The Drop Tolerance is equivalent to the Maximum Return Loss that is allowable
for any Drop detected in the scatter data. The return loss of a Drop is calculated
by integrating the power of an area centered around the feature that has a length
equivalent to the Feature Extract Length.
Default Value: -68 dB
Closely Related To: Feature Extract Length
6
