• Calibrate calls up a dialog box which allows the user to specify the
calibration settings and begin a calibration. (See “Calibrating the
System” on page 35 for complete calibration instructions.)
• Align Optics performs an alignment of the internal optics of the
OBR. See “Aligning the OBR Optics” on page 34 for more infor-
mation about system alignment.
• Calibration Information calls up a screen with information on the
laser calibration currently in use.
• Specify Calibration Filenames allows the user to use the default
calibration filename (obrCal_refl), or to uncheck this box and
type
in
or select a new calibration filename. For further details, see “Cal-
ibration Files” on page 36.
• Reload Calibration Data reloads the most recent valid calibration
data. This may be used when a calibration fails or is cancelled by
the user.
• Install New Feature Key calls up a dialog box where the user may
enter a key string provided by Luna Technologies, in order to
unlock a newly purchased software feature.
• Reset Hardware allows the user to reset the OBR hardware with-
out having to turn off the device. This should only be used in the
rare event that the device becomes non-responsive. This command
will close the software and thus requires the user to restart the OBR
software.
The Help menu
• About OBR 4600 displays information about the current software
version and contact information for Luna Technologies.
• Version Information calls up a dialog box showing the OBR hard-
ware version. This information is used by Luna Technologies for
upgrading OBR hardware.
