Luna 4600 - Page 159

Optical Backscatter Reflectometer 4600 145
User Guide
graphType Graph/Parameter Name
Time Domain (domain = 0) Values
0
Amplitude
1
Linear Amplitude
2
Polarization States
3
Phase Derivative
4
Amplitude (dB)
5
Spectral Shift (only on some units)
6
Temporal Shift (only on some units)
7
Strain (only on some units)
8
Temporal Shift (only on some units)
Frequency Domain (domain = 1) Values
0
Return Loss
1
Linear Amplitude
2
Polarization States
3
Group Delay
7
GraphType can take values from 0 to 8, as shown above.
However, parameters 5 through 8 are only available when
purchased as a separate option. The assignment of
graphType depends on which domain is specified. (Note
that this list of values for graphType may be retrieved using
the FETC:GNAM? query, below.)
Decimate can be set to 1 to use decimation, or 0 to return
all points.
Description: Retrieves the size of the data arrays; i.e. the number of data
samples to expect from the FETC:MEAS? queries.
All parameters must be specified.
