8 Chapter 2

Assembly and Startup

One (1) power cord for the OBR instrument. (Plus two (2)

more, if you ordered the PC and monitor)

OBR laptop PC (or desktop PC, shown below)

Laptop power supply

OBR desktop PC (or laptop PC, shown above)
