MacDon PW8 - Lubricating Auger Drive Chain

214658 142 Revision A
6.4.2 Lubricating Auger Drive Chain
DANGER
To avoid bodily injury or death from unexpected startup of machine, always stop engine and remove key
from ignition before leaving operator’s seat for any reason.
1. Lower header to the ground, shut down the combine, and remove the key from the ignition.
1006516
A
Figure 6.136: Left Endshield
2. Open left endshield (A). For instructions, refer to 3.3.1
Opening Left Endshield, page 20.
1018356
A
Figure 6.137: Auger Drive Chain
3. Apply a liberal amount of SAE 30 engine oil to the
chain (A).
4. Close left endshield. For instructions, refer to 3.3.2
Closing Left Endshield, page 20.
PREDELIVERY INSPECTION
