MacDon PW8 - Removing Flighting Extensions

214658 44 Revision A
4.3.2 Removing Flighting Extensions
Follow these steps to configure the auger flighting extensions for a 1651 mm (65 in.) feeder house:
1006481
A
Figure 4.32: Access Holes in Auger
1. Remove the two access covers (A) on both sides of
center.
1011654
A
B
Figure 4.33: Left Flighting Extension – Right
Extension Opposite
2. Remove hardware (A) securing existing left and right
auger flighting extensions (B) and remove extensions.
IMPORTANT:
To avoid damage to auger, check that all loose
hardware and tools are removed from inside the auger.
RECONFIGURING HEADERS
