2.15 BATTERY ROOM DOOR
• When performing inspection and maintenance inside the door, be sure to fix the door in
an open condition by using the stopper.
1. Insert your finger into the door pull (1) and open the door
(2).
2. After opening the door (2), put the rod (3) in the groove
to fix.
3. To close the door (2), lift the rod (3) to remove it from
the groove and close the door.
2.16 LEFT COVER
• When performing inspection and maintenance inside the door, be sure to fix the door in
an open condition by using the stopper.
• Be sure to lock the door except when opening it.
1. Disengage the lock (1) of door locking.
2. Insert your finger into the door pull (2) and open the door
(3).
3. After opening the door (3), put the rod (4) in the groove to
fix.
4. To close the door (3), lift the rod (4) to remove it from
the groove and close the door.
5. Lock the door.
