[8] CHECKING ELECTRIC WIRING
• When a fuse blows frequently or there is a trace of short circuit in the electric wiring,
immediately request us or our sales service agency for the investigation of the cause and
repair.
• Keep the top face of the battery clean and inspect the vent hole of the battery cap. If it is
clogged with mud, wash the battery cap with water to remove clogging.
Inspect if fuses are damaged, fuses of the specified capacity are used, there is a trace of a break or
short circuit in the electric wiring, sheaths are damaged or terminals are loosened. If loosened,
retighten them.
In particular, inspect the wiring of "Battery", "Starter" and "Alternator".
Be sure to inspect if combustibles accumulate around the battery and remove them.
[9] CHECKING WORKING LAMP
Check if the working lamp and headlamps turn on properly or
if they are dirty or damaged.
1. Turn the starter switch to the "ON" position.
2. Turn the lamp switch to the "ON" state to check if the
working lamp turns on.
If it does not, a blown bulb or wiring failure is likely. Contact
us or our sales service agency for repair.
[10] CHECKING HORN FOR FUNCTION
1. Turn the starter switch to the "ON" position.
2. Press the horn switch to verify that the horn sounds at once.
If the horn does not sound, contact us or our sales service
agency for repair.
