operation. Do not replace the elements immediately. Wait until the oil is cooled.
• When removing the oil inlet cap, turn it slowly to relieve the internal pressure in order
to prevent the oil from spurting out.
1. Loosen the bolts to remove the cover (1) on top of the
hydraulic oil tank.
2. Remove the cap of oil inlet (F) to relieve the internal
pressure.
3. Replace the element (2) inside the cap.
4. Mount the cap of oil inlet (F).
5. Attach the cover (1) on top of the hydraulic oil tank.
To Next Page
