[LOOSENING THE TENSION]
Discharging grease without using the following procedure is extremely dangerous. If
the rubber track is not loosened, request us or our sales service agency for repair.
1. Slowly loosen the plug (1) to discharge the grease.
When loosening the plug (1), loosen it for only one turn
at the most.
NOTES
If the grease cannot be smoothly discharged, slightly
move the Machine back and forth.
2, Screw in plug (1).
3. To ensure that a proper tension is applied, keep the
engine at an idling speed to travel forward for a
distance equal to the length of rubber track in contact
with the ground, and slowly stop travelling.
4. Check the tension of rubber track again.
If the tension is not appropriate, make another
adjustment.
[7] CHECKING/REPLENISHING WINDOW WASHER SOLUTION
If air is entrapped in the window washer solution, check
the level of solution in the window washer tank (1), and if
it is not enough, replenish with window washer solution
for automobiles.
NOTES
When replenishing the window washer solution, pay
attention to keep it free from dust.
[PROPORTION OF UNDILUTED WINDOW WASHER
SOLUTION AND WATER]
Since the adequate proportion varies with temperature,
add the window washer solution mixed with water at the
following proportions:
Area and
Season of Using
the Solution
Mixing Proportion
Freezing
Temperature
Normal
1/3 of undiluted liquid
with 2/3 of water
-10°C
Winter in cold
region
1/2 of undiluted liquid
with 1/2 of water
-20°C
Winter in
extremely cold
region
Undiluted -30°C
The user can select from two types provided for different
temperatures of -10°C (for general services) and for
-30°C (for extremely cold region) by also taking into
account of the area and season of service.
