•Always use the designated place on the machinery cover, or you may slip and fall down.
See "Safety 1.4 Cautions in getting on and off" for details.
• When performing inspection and maintenance inside the machinery cover, be sure to fix
the machinery cover in an open condition by using the machinery cover supporting rods.
• Be sure to close the machinery cover for operation except for inspection.
1. Insert the key into the machinery cover open knob (1) to
make it "an open state".
2. After pulling out the key, open the machinery cover (2)
while pushing the machinery cover open knob (1).
3. After opening the machinery cover, fix the machinery
cover supporting
rods (3) to the machinery cover fixing
position.
4. To close the machinery cover (2), remove the machinery
cover supporting rods (3) and securely fix it to the lever
lock. Then, gently lower the machinery cover and push
down the machinery cover to lock.
5. Insert the key into the machinery cover open knob (1) to
make it "a lock state".
2.19 HOLDER FOR OPERATION MANUAL
A pocket for storing the operation manual is provided in the
left side of the cab.
Put the operation manual in this pocket so that you can see
it whenever you need it.
