• See “MAINTENANCE 7.1 USE OF FUEL AND LUBRICATING OIL ACCORDING TO
TEMPERATURES” for the oil to be used. Using oil other than those specified may shorten
the life of the engine. Be sure to refill with the specified oil.
• Keep the engine oil at an appropriate level.
The oil level being too high will result in too much oil consumption
increase the oil temperature, deteriorating the oil faster. The oil level being too low may
burn out the engine.
• Be careful not to let any foreign substance go into the filler opening when refilling the oil.
1. Place the machine on a level surface.
2. Open the machinery cover.
3. Pull the oil level gauge (1) out and wipe the oil with a
disposable cloth.
4. Insert the oil level gauge (1) into the gauge guide as far as
it goes and pull it out.
5. If the oil level is between the “Ｈ” mark and “Ｌ” mark on the
oil level gauge (1), the oil level is normal.
6. If the oil level is lower than the “L” mark, remove the oil filler
cap (2) and refill the engine oil from the filler opening.
7. Securely install the oil level gauge (1) and filler cap (2) after
refilling the oil.
If the oil level is above the "H" mark, remove the under
cover, drain the excess quantity from the drain bolt (3)
and check the oil level again.
