146
3. After refilling, securely tighten all the caps (2).
NOTES
If purified water
should be refilled above the highest
electrolyte level line, use a syringe to extract it up to the
highest electrolyte level line.
For the extracted liquid, after neutralizing it with baking
soda, wash it away with a lot of water. Or consult us or our
sales service agency, or battery manufacturer.
[WHEN CHECKING ELECTROLYTE LEVEL FROM BATTERY TOP]
Check in the following method if the electrolyte level cannot be checked from the battery side or
there is no indication of "UPPER LEVEL" (highest electrolyte level line) on the side.
1. Lift up the vinyl cover (1) installed on the battery.
2. Remove all the caps (2) on the top face of the battery and
look into the liquid filling opening (3) to check.
3. If the electrolyte level does not reach the sleeve (4), be sure
to refill purified water up to the bottom (highest electrolyte
level) of the sleeve (4).
• (A) Proper amount: As the electrolyte level reaches the
bottom of the sleeve, it swells due
to surface tension and the plate
looks contorted.
• (B) Small amount: As the electrolyte level does not reach
the bottom of the sleeve, the plate
does not look contorted and looks
plate-like in shape.
4. After refilling, securely tighten all the caps (2).
NOTES
If purified water should be refilled above the bottom of the sleeve, use a syringe to extract it up to
the bottom of the sleeve.
For the extracted liquid, after neutralizing it with baking soda, wash it away with a lot of water. Or
consult us or our sales service agency, or battery manufacturer.
[WHEN ELECTROLYTE LEVEL CAN BE CHECKED BY INDICATOR]
If the electrolyte level can be checked by the indicator, etc., follow the instruction.
