323
[Posture of the 60 degrees angled Fly-jib]
CAUTION
The posture in the figure on the right shows
that the No.2 Fly-jib is extended in accor-
dance with the procedure 1.~ 4. as above.
In this posture, the signal indicating that
Fly-jib length is two stages is transmitted to
the moment limiter and the display of the
number of the Fly-jib stage of the monitor is
changed to “2”.
