- 76 -

LAYOUT 7 [io-std07.iom] LAYOUT 8 [io-std08.iom] LAYOUT 9 [io-std09.iom]

OUT IN OUT IN OUT

Easy BOX U8IO

N°1

1 Start (T3) Start/Stop (T2) Redo Step

2 Stop (T3) Zeroing mode Zeroing mode

3 Redo Step Next Zero Step Next Zero Step

4 Zeroing mode Ready Disable Stat

5 Next Zero Step

Running Running

6 Ready Part Good Part Good

7 Part Good Part Reject Part Trend

8 Part Reject Error Part Reject

Easy BOX U8IO

N°2

1 - Batch code bit3 (MSB) Batch code bit2 (MSB)

2 - Batch code bit2 Batch code bit1 (LSB)

3 - Batch code bit1 (LSB) -

4 - Disable Stat -

5 - Redo Step -

Part Trend -

7- - -

8- - -

Easy Box (NON

U8IO) N.1,2,3,4

1 Start/Stop (T1) Start/Stop (T1) Start/Stop (T1)

Easy Box U4S 1 Start/Stop (T1) Start/Stop (T1) Start/Stop (T1)

Easy Box U4P

1 Start (T3) Start (T3) Start (T3)

2 Stop (T3) Stop (T3) Stop (T3)

3 Zeroing mode Zeroing mode Zeroing mode

4 Next Zero Step Next Zero Step Next Zero Step

M1 Wave N.

1,2,3,..16

1 Start/Stop (T2) Start/Stop (T2) Start/Stop (T2)

Digi Crown I/O N°1
