- 77 -
LAYOUT 10 [io-std10.iom] LAYOUT 11 [io-std11.iom] LAYOUT 12 [io-std12.iom]
IN
OUT IN OUT IN OUT
Easy BOX U8IO
N°1
1 Redo Step - Zeroing mode
2 Zeroing mode - Measuring mode
3 Emergency (active low) - Next zero step
4 Motor out --
5
Running --
6
Part Good --
7
Part Trend --
8
Part Reject --
Easy BOX U8IO
N°2
1 Batch code bit2 (MSB) - Batch code-Part Type bit1 (LSB)
2 Batch code bit1 (LSB) - Batch code - Part Type bit2
3 Next Zero Step - Batch code - Part Type bit3
4 Disable Statistics - Batch code - Part Type bit4 (MSB)
5- -
Batch code - Spindle Type (tipo mandri-
no) bit 1 (LSB)
6 - - Batch code - Spindle Type bit 2
7 - - Batch code - Spindle Type bit 3
8 - - Batch code-Spindle Type bit 4 (MSB)
Easy Box (NON
U8IO) N.1,2,3,4
1 Start/Stop (T1) - Start/Stop/Get Zero (ottieni zero) (T2)
Easy Box U4S 1 Start/Stop (T1) - Start/Stop/Get Zero (T2)
Easy Box U4P
1 Start (T3) Start /Data OK (dati OK) (Type 2) -
2 Stop (T3) Get zero (one shot (unico tentativo)) -
3 Zeroing mode Redo Step / Redo Part (ripeti pezzo) -
4 Next Zero Step Next Page (prossima pagina) -
M1 Wave N.
1,2,3,..16
1 Start/Stop (T2) - Start/Stop/Get Zero (T2)
Digi Crown I/O N°1
1 Redo Step - -
2 Zeroing mode - -
3 Next Zero Step - -
4 Disable Stat - -
5
Running --
6
Part Good --
7
Part Trend --
8
Part Reject --
Digi Crown I/O N°2
1 Batch code bit2 (MSB) - -
2 Batch code bit1 (LSB) - -
3- - -
4- - -
5- - -
6- - -
7- - -
8- - -
To Next Page
