LAYOUT 13 [io-std13.iom] LAYOUT 14 [io-std14.iom] LAYOUT 15 [io-std15.iom]

OUT IN OUT IN OUT

Easy BOX U8IO

N°1

1 Batch code bit 7 (MSB) Data OK Batch code bit 7 (MSB)

2 Batch code bit 6 Get Zero (one shot) Batch code bit 6

3 Batch code bit 5 Next Page Batch code bit 5

4 Batch code bit 4 Message OK Batch code bit 4

5 Batch code bit 3 Batch D Batch code bit 3

6 Batch code bit 2 Batch C Batch code bit 2

7 Batch code bit 1 (LSB) Batch B Batch code bit 1 (LSB)

8 Start /Stop/Get Zero (T2) Batch A Start /Stop/Get Zero (T2)

Easy BOX U8IO

N°2

1 Redo Step - -

2 Zeroing mode - -

3 Emergenza (attivo “low”) - -

Motor out --

Running --

Part Good --

Part Trend --

Part Reject -

Easy Box (NON

U8IO) N.1,2,3,4

1 Start/Stop/Get Zero (T2) - Start/Stop/Get Zero (T2)

Easy Box U4S 1 Start/Stop/Get Zero (T2) - Start/Stop/Get Zero (T2)

Easy Box U4P

1 - Data OK -

2 - Get Zero (one shot) -

3 - Next Page -

4 - Message OK -

M1 Wave N.

1,2,3,..16

1 Start/Stop/Get Zero (T2) - Start/Stop/Get Zero (T2)

Digi Crown I/O N°1

1- - -

2- - -

3- - -

4- - -

5- - -

6- - -

7- - -

8- - -

Digi Crown I/O N°2
