- 79 -
LAYOUT 18 [io-std18.iom] LAYOUT 22 [io-std22.iom] LAYOUT 23 [io-std23.iom]
IN
OUT IN OUT IN OUT
Easy BOX U8IO
N°1
1 Start /Stop/Get Zero (T2) - Start/Stop (T2)
2 Zeroing mode - Redo step
3 Batch code bit 1 (LSB)* - Batch F
4 Batch code bit 2 - Batch E
5 Batch code bit 3 - Batch D
6 Batch code bit 4 (MSB) - Batch C
7 - - Batch B
8 - - Batch A
Easy BOX U8IO
N°2
1 - - Zeroing mode
2 - - Next Zero step
3- - -
4- - -
5- - -
6- - -
7--
8--
Easy Box (NON
U8IO) N.1,2,3,4
1 Start/Stop (T1) Start/Stop (T1) Start/Stop (T1)
Easy Box U4S 1 - Start/Stop (T1) Start/Stop (T1)
Easy Box U4P
1 - Start (T3) Start (T3)
2 - Stop (T3) Stop (T3)
3 - Batch A Zeroing mode
4 - Batch B Next Zero Step
M1 Wave N.
1,2,3,..16
1 - Start/Stop (T1) Start/Stop (T2)
Digi Crown I/O N°1
1 - - Start/Stop (T2)
2 - - Redo step
3 - - Batch F
4 - - Batch E
5 - - Batch D
6 - - Batch C
7 - - Batch B
8 - - Batch A
Digi Crown I/O N°2
1 - - Zeroing mode
2 - - Next Zero step
3- - -
4- - -
5- - -
6- - -
7- - -
8- - -
* Binary value (0=Batch 1, 15= Batch 16)
* Binary value (Batch A=Batch 1, Batch
B=Batch 2)
