4 On test lead set labeled VT H/P connect the high voltage connector color coded green to the MVCT
high voltage connector that is color coded green and labeled SOURCE Voltage. Use the red
alignment marks on the 2 connectors to properly align them before connecting.
5 On test lead set labeled VT X/S Connect the high voltage connector color coded blue to the MVCT
high voltage connector that is color coded blue and labeled MEASUREMEMT. Use the red alignment
mark on the 2 connectors to properly align them before connecting
6 On test lead set labeled VT H/P connect the test lead binding posts H0 and H1 to primary of the
voltage transformer on the H0 and H1 terminals. Observe the polarity marks on the VT (HO on test
set is polarity terminal).
7 On test lead set labeled VT X/S connect the test lead binding posts X0 and X1 to VT secondary
terminals X0 and X1. Observe the polarity marks on the VT (X0 on the test set is polarity terminal).
8 Turn Power ON/OFF switch to ON.
9 After the boot up, put the MVCT in VT Testing Mode by selecting the VT button at the top of the
home screen.
10 After the VT mode is selected in the Home Screen select the “Ratio Test” button .
WARNING
The MVCT produces high voltages and currents during the performance of tests. DO NOT
TOUCH connector clips or test leads while the MVCT is performing a test.
