Megger MVCT - Testing Mode; CT Testing Mode - Menu Items

32
File Manager
Refer to each menu item below for detailed description
5.4 Testing Mode
Depending upon how the MVCT was ordered, it has the capability of different modes of testing. By
selecting the desired mode of testing, the MVCT can be placed in either CT Testing, VT Testing, or Relay
testing mode of operation. The mode is selected by choosing the CT, VT, or Relay button at the top of
the Home Screen. The active mode of operation is indicated by button being highlighted in yellow.
5.4.1 CT Testing Mode – Menu Items
Menu items are considered either system wide menu items or menu items that are available only within
a specific mode of testing. Below are all the menu items available when the MVCT is set up for test CT’s
5.4.1.1 Device Connections
Selection of Device Connection button will initialize the connection to the MVCT
5.4.1.2 Device Settings
Selection of Device Settings, brings the user the following screen.
