158
Connection Diagram Three Phase Reactor
CT Locations
Tests Set Connections
X1 X2 H1 H2
Jumpers
X Bushing
Secondary of CT
located in control
cabinet
X Bushing
Neutral Bushing
All CT not under
Test
X Bushing - GND
Y Bushing - GND
Z Bushing - GND
Y Bushing
Secondary of CT
located in control
cabinet
Y Bushing
Neutral Bushing
All CT not under
Test
X Bushing - GND
Y Bushing - GND
Z Bushing - GND
Z Bushing
Secondary of CT
located in control
cabinet
Z Bushing
Neutral Bushing
All CT not under
Test
X Bushing - GND
Y Bushing - GND
Z Bushing - GND
