WIRING DIAGRAMS
Page 2D-4 90-884294 OCTOBER 2001
Commander 3000 Classic Panel Remote Control
F
R
<>
RED
PURPLE
GREEN
BLK = Black
BLU = Blue
BRN = Brown
GRY = Gray
GRN = Green
ORN = Orange
PNK = Pink
PUR = Purple
RED = Red
Tan = Tan
WHT = White
YEL = Yellow
LIT = Light
DRK = Dark
a
a
a-Neutral Interlock Switch

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercury 225 EFI and is the answer not in the manual?

Mercury 225 EFI Specifications

General IconGeneral
Engine TypeV6
Horsepower225 hp
SteeringRemote
Fuel Induction SystemElectronic Fuel Injection (EFI)
Alternator Output60 Amp
Shaft Length20", 25"
Weight505 lbs
Full Throttle RPM Range5000-5800
