IGNITION
90-884294 OCTOBER 2001 Page 2A-35
Crank Position Sensor Removal
1. Disconnect sensor harness.
2. Remove screws securing sensor to engine.
59070
b
a
a-Crank Position Sensor b-Harness Connector
Crank Position Sensor Installation
1. Secure sensor to engine with 2 screws. Torque screws to 45 lb. in. (5 Nm).
2. Reconnect sensor harness.
