CHARGING & STARTING SYSTEM
Page 2B-18 90-884294 OCTOBER 2001
Current Output Troubleshooting
Current Output is Low Battery Cables are loose or corroded
Defective Battery (Open Circuit)
Defective Alternator
Current Output is High Accessories turned on
Defective Battery (Internal Short)
Defective Alternator
Repair
Removal
1. Remove top cowling.
2. Disconnect battery cables from battery.
3. Disconnect wiring harness from alternator.
4. Remove belt from alternator.
5. Remove attaching bolts.
59067
a
b
a-Attaching Bolt b-Harnesses

Mercury 225 EFI Specifications

General

Engine Type	V6
Horsepower	225 hp
Steering	Remote
Fuel Induction System	Electronic Fuel Injection (EFI)
Alternator Output	60 Amp
Shaft Length	20", 25"
Weight	505 lbs
Full Throttle RPM Range	5000-5800
