POWERHEAD
Page 4A-28 90-884294 OCTOBER 2001
Vapor Separator Tank (VST) Removal
CAUTION
Depressurize fuel system prior to opening line connections or removing fuel sys-
tem components.
1. Use Fuel/Air Pressure Gauge 91-16850A7 or Fuel Pressure Gauge 91-881834A1 to de-
pressurize fuel system. Direct fuel into suitable container.
2. Remove VST drain plug and allow fuel to empty into suitable container.
59053
c
a
b
a-Fuel Pressure Gauge 91-881834A1
b-Fuel Pressure Test Port
c-Drain Plug
